500/1+6+12 Tubular Stranding Machine Tubular Strander 500/1+6 strander for steel wire strand Cu strand and ACSR

I'm Online Chat Now

500/1+6+12 Tubular Stranding Machine Tubular Strander 500/1+6 strander for steel wire strand Cu strand and ACSR

China 500/1+6+12 Tubular Stranding Machine Tubular Strander 500/1+6 strander for steel wire strand Cu strand and ACSR supplier

Large Image :  500/1+6+12 Tubular Stranding Machine Tubular Strander 500/1+6 strander for steel wire strand Cu strand and ACSR

Product Details:

Place of Origin: China
Brand Name: Jixin
Certification: ISO9001
Model Number: JGG 500/1+6

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD+45000+set
Delivery Time: 30-40 days
Payment Terms: T/T, Western Union
Supply Ability: 15 sets month
Detailed Product Description
Color: Sky Blue

 500/1+6+12 Tubular Stranding Machine Tubular Strander 500/1+6 strander for steel wire strand Cu strand and ACSR

Specification 200/1 6 400/1 6 400/1 12 500/1 6 630/1 6

Dia. of inlet (mm) copper 0.7-2.5 1.0-3.0 1.5-4.0 1.8-5.0
Aluminium 1.0-3.0 1.5-3.5 1.8-4.0 2.0-5.0
steel 1.0-2.0 1.0-2.5 1.5-3.0 1.8-4.0
mixed 4 5 5 5
Production dia. mm 12 15 25 15
Stranding cage speed 1000 600 500 500 350
Stranding pitch mm 4.1-74.7 26-238 49-450
Diameter of wheel haul-off(mm) 318 800 1000 1250

Size of take-up reel 630 1250 1600 1800



Tubular strander for 800 1000 1250 bobbins are avaliable.



This equipment is used for twisting copper strand, aluminum strand, steel strand, steel-cored aluminum strand and wire rope. After coiling, it can twist insulation wire and some control wire.

Main Character

1. The machine can work steadily with the whole holder, and the protect cover adopts high grade seamless steel tube, so the structure is also steady with lower noises.

2. The timing power can be manipulated easily to adjust the speed .The protect cover has the right and reverse direction circumrotate.

3. The main machine and the haul-off unit adopt shift gears case, so the working intensity is lower and the pitch is exact.

4. Equipped with automatic parking equipment -the safeguard, it means the machine will stop when the thread runs out or the door is open.

Configuration

Rear-positioned pay-off, mainframe, tape lapper, haul-off unit, take-up and electrical system.
